3G GPS Tracker Car GPS TK915-3G With 80 days Standby Waterproof Magnet Realtime GPS Locator Car Tracker Shock Alarm Free APP
1. The TK915-3G is 3G Version, can be also compatible with 2G network:
WCDMA supports HSDPA/UMTS/EDGE/GPRS/GSM
UMTS: 850/900/1900/ 2100 MHz
GSM Band frequency ( Global use): 850/900/1800/1900MHz
2. Tracking Software:
* About Web tracking platform:
Free Web tracking software,no charge fee,login page : www.mytkstar.net
Select “Log in by IMEI/ID” on the bottom of screen
ID No. : on the back side of cover
Default Password: 123456
* About Mobile APP Android/IOS Tracking:
Scan the QR Code to install the applications on your cell phone.Register and add account.
Search “TKSTAR GPS” in the Apple App Store/Google Play Store or Scan the QR Code to install
the applications on your cell phone.
3. How to log in mobile APP and web server?
A. Set APN: by sending a SMS command to the SIM card inside device: APN123456+space+content, for example: APN123456 cmnet
(please use your local APN instead of CMNET,if you do not know the APN content,you should contact your SIM card supplier)
B. Set IP and Port of TK905-3G: adminip123456+space+ip+space+port (ip address of www.mytkstar,net is 220.127.116.11, and port of 7700)
for example: adminip123456 18.104.22.168 7700
Note: 123456 is the default password from our factory, if you have changed th password, please use the correct one
C. Open GPRS: by sending a SMS command to the SIM card inside device: GPRS123456
Dim: 112mm * 77mm * 27mm (4.4″ * 3.1″ * 0.9″)
* Weight: 300g
* Network: 2G GSM/GPRS
* WCDMA supports HSDPA/UMTS/EDGE/GPRS/GSM
UMTS: 850/900/1900/ 2100 MHz
* Band: 850/900/1800/1900Mhz
* GPS sensitivity: -159dBm
* GPS accuracy: 5m
* Wall charger: 110-220V input 5V-1A output
* Battery: Chargeable 3.7V 7800mAh Li-ion battery
* Stand by time: 80days
* Storage Temp.: -40°C to +85°C
* Operation Temp.: -20°C to +55°C
* Humidit: 5%–95% non-condensing
3G Car GPS Tracker / GPS Assets with Powerful Magnet and Large Battery TK915-3G
1. Long Standby Time: It has built-in 3.7V 7800mAh Li-ion battery, can standby up to 80 days(Maximum standby time in sleep model).
2. Powerful Magnetic: It has 5pcs built-in magnets,with super strong powerful magnetic,can be very easily installed.
3. Remotely Voice Monitor: Send “Monitor+Password” to the device first, then the device will turn into monitor mode, now if you make call to the SIM number in the device, it will pick up your call automatically and you will can monitor the voice around the device!
4. Overspeed Alarm: This alarm works only under continuous positioning mode.When the unit speed is exceed the speed you presetted, it will send message “speed alarm!” to the admin number every 5 minutes.
5. Shake Alarm: After you did the shake alarm setting,please keep the tracker being stationary for 5 minutes, then this function will start working. It will send SMS “sensor alarm!” to the admin number when the unit get shocked.
6. Sleep Mode:* Sleep by time mode: After did this setting, tracker will only work for 5 minutes after being waked up, and back to sleep mode, GPS will shut off and GSM will works in low consumption mode. SMS, call will can wake up the tracker. * Sleep by shock sensor mode: After did this setting, if no shock for 5 minutes, the tracker will work under “sleep by shock” mode, GPS will shut off, GSM will works in low consumption. Vibration, SMS, call will can wake up the tracker.
7. History Route Playback: You can track the history route of the device up to 6 months via both the web platform and APP.
8. Lifetime free WEB Tracking platform and Mobile APP Android/IOS Tracking: no any yearly subscription.
